JAY Encompass Back
ManufacturerSunrise Medical
ModelSBK90XX
$446.25MSRP $595.00
Most items ship in 3 to 7 business days.
Sunrise builds the JAY Encompass to order for someone who needs firm support at the sides and front of the trunk. Pick the size, foam and laterals, and your order carries Sunrise's part numbers.
A back built to order for the most support JAY makes
Sunrise's most configurable JAY back, 14" to 25" wide and 12" to 28" tall, with three-piece laterals.
Built for real life
What stands out
●
Three-piece laterals
A posterior lateral on each side can carry a swing-away anterior lateral. Together they hold the trunk at the side and the front, and the front piece swings clear for transfers.
●
The widest size range in JAY
12 widths from 14" to 25" and 17 heights from 12" to 28", in 1" steps, cover more torso sizes than any other JAY back.
●
Foam built to your order
Start from 1" High Resiliency foam or choose T-Foam, Sunmate or gel, in the thickness and firmness you need. Extra HR foam goes on in 1/2" layers.
●
Everything to mount it
The package includes the back, removable 4-point mounting hardware with 15° of angle adjustment and a universal headrest adapter plate.
The Hieline Take
The Encompass suits someone whose trunk leans or falls to the side and who needs to be held from the front as well. It weighs 8 lbs., so it makes sense when a J3 with laterals no longer holds the posture. Order your chair's width and the lowest height that gives the support you need. Take the standard lateral size for your chair width unless your clinician says otherwise, and add the swing-away anterior laterals on the side that needs them, since they swing clear for transfers. For foam, the 1" standard plus the base layer is 1.5", so Sunrise's 2" total means a 1.5" modification or one 1/2" layer of extra HR foam.
Straight talk
Is it right for you?
A good fit if you
need firm support at the sides and front of the trunk
use a wheelchair 14" to 25" wide with 7/8" or 1" back canes
want the foam and laterals chosen to your needs
Look elsewhere if you
weigh more than 250 lbs.
need light support, which the JAY J3 PA or PL shell gives for less
want to try it and send it back, because it is built to order
Specifications
ManufacturerSunrise Medical, JAY brand
Back typeConfigurable back with three-piece lateral thoracic supports
Widths14" to 25", by wheelchair width
Heights12" to 28" in 1" steps
ShellContoured three-piece aluminum shell
Foam1/2" closed cell base layer with 1" High Resiliency foam as standard; T-Foam, Sunmate and gel modifications
CoverBlack AirExchange contact surface, Dartex non-contact surface; no other upholstery
LateralsPosterior laterals Small to Large, 9.5" to 11.75" high; swing-away anterior laterals 6.25" to 7.75" high, 6" contoured
Hardware4-point, removable, with 15° of angle adjustment
The JAY Encompass Back is covered by Sunrise Medical's own limited warranty. The coverage we have on record is below.
BackSunrise Medical limited warranty against defects in materials and workmanship
NoteSunrise publishes no owner's manual for the Encompass, so no warranty term in months is stated here
This product cannot be returned
Sunrise builds each Encompass to your order, so it cannot be returned once ordered. Check your wheelchair's width and the back height before you order. The warranty is unaffected, so a defect is still covered.
If something goes wrong
Call us first at 1-855-HIELINE. We file the claim with Sunrise Medical for you and get the covered part sorted out rather than handing you a phone number.
What comes in the package?
The Solid Back Package, Sunrise's SBK90XX, is the back in your size (ENC1000 at 18" tall and under, ENC1010 above), the removable Encompass mounting hardware (ENC1500) and the universal headrest adapter plate (HR0001S). Foam modifications and laterals are added in the build steps.
Which width do I order?
Order your wheelchair's width. The back fits between the back canes, so a 16" chair takes a 16" Encompass. Without laterals the back measures 6.8" less than the chair, and the laterals fill the space at the sides.
Which lateral size fits my chair?
Sunrise's standard size is Small on a 14" to 16" chair, Medium/Small at 17" to 19", Medium/Large at 20" to 22" and Large at 23" to 25". A swing-away anterior lateral mounts on a posterior lateral, so it is sold here with the posterior lateral of the same size.
How much foam should I choose?
Sunrise recommends 2" of foam in total on the back, including the 1/2" closed cell base layer, and 1" in total on each lateral. The foam and extra HR foam steps set the back; the laterals ship with Sunrise's standard foam.
Can I order personalized laterals?
No. Sunrise prices personalized posterior and anterior laterals by quote, so they are not sold here. The four standard sizes are.
Does it take a headrest?
Yes. The universal headrest adapter plate is in the package. A headrest and its mount are not sold on this page.
What is the weight capacity?
250 lbs., the figure on Sunrise's page and in the JAY catalog.
Can I return it?
No. Sunrise builds the Encompass to your order, so it cannot be returned once ordered. A defect is still covered by the warranty.
Shipping is free on orders of $500 or more and $45 below that, to any address in the 48 continental states. Most items ship in 3 to 7 business days. No carrier quotes an exact date, so treat that as an estimate rather than a promise.
Standard shipping$45.00 at checkout
$45 to the 48 continental states, free on orders of $500 or more. Most items ship in 3 to 7 business days.
