Spinergy SLX 507 Rear Wheels
ManufacturerSpinergy
ModelSLX 507
$958.50
Starting price
Most items ship in 3 to 7 business days.
The Spinergy SLX 507 is a wheelchair wheel on a 507mm rim for mountain bike style tires, with 18 PBO fiber spokes of 4mm. It is sold as a pair of bare wheels with black spokes.
The SLX 507 is a Spinergy wheel on a 507mm rim, the size of youth mountain bike and BMX tires, with 18 PBO fiber spokes of 4mm. It is sold as a pair with black spokes, with or without rivnuts.
Built for real life
What stands out
●
507mm rim
The size of youth mountain bike and BMX tires, so a wide range of off-road and large volume tires fits.
●
For rough ground
Spinergy names gravel, grass and dirt with a knobby tire, and rough pavement or a power assist with a large road tire.
●
18 spokes of 4mm
Each wheel has 18 radial spokes of PBO fiber in Spinergy's thick 4mm size.
●
SLX sport hub
The hub measures 2.3" between the bearings and takes a 1/2" axle.
●
Silver or black hub
Black spokes with a silver hub or a black one.
●
With or without rivnuts
Rivnuts are threaded inserts set in the rim.
The Hieline Take
The SLX 507 exists for one reason, which is the tire. A 507mm rim takes the tires made for youth mountain bikes and BMX bikes, so you can run a wide knobby tire for gravel, grass and dirt, or a large volume road tire to soften rough pavement or to suit a power assist. Spinergy builds it with its thick 4mm spokes and the SLX sport hub. The size needs thought before you order. Spinergy describes 507mm as slightly larger than a 22" (501) wheel, and a wide tire adds height and width on top of that, so check the clearance on your frame and your wheel locks. The list carries it with black spokes only, with a silver or a black hub, and with or without rivnuts in the rim. The wheels arrive bare, and wheels cannot be returned.
Straight talk
Is it right for you?
A good fit if you
ride on gravel, grass or dirt
want a large tire to soften rough ground
use a power assist and want a bigger tire
Look elsewhere if you
have not checked the clearance on your frame
want colored spokes
want an indoor wheel for a narrow chair
Specifications
ManufacturerSpinergy
ModelSport Lite Extreme SLX 507
TypeRear wheel for mountain bike style tires, sold as a pair
Size507mm rim. Spinergy describes it as slightly larger than a 22" (501) wheel.
Spokes18 per wheel, PBO fiber, 4mm round, radial laced, black
Wheel weight714 g per wheel
HubSport hub, 2.3" bearing spacing
BearingsStainless steel, sealed, 1/2"
Hub colorSilver or black
RimStandard, or with rivnuts
Tires507mm tires: a mountain bike style tire, or a large volume road tire
IncludedTwo wheels with hubs and bearings
Not includedHandrims, tires, tubes and axles
Part numbersSLX.507.18.111 with a silver hub and SLX.507.18.111B with a black hub. "-RIV" at the end is the rim with rivnuts.
Warranty1 year
Selected option
Manufacturer modelSLX 507
Size and fit
Every size is listed here for reference. Choose your size in Build & Buy above.
Rim
Hub
Model
Price
Standard rim
Silver hub
SLX.507.18.111
$958.50
Standard rim
Black hub
SLX.507.18.111B
$958.50
Rim with rivnuts
Silver hub
SLX.507.18.111-RIV
$985.50
Rim with rivnuts
Black hub
SLX.507.18.111B-RIV
$985.50
The Spinergy SLX 507 Rear Wheels is covered by Spinergy's own limited warranty. The coverage we have on record is below.
Wheels1 year from the date of purchase against defects in materials and workmanship, for the original owner, with proof of purchase
What Spinergy doesRepairs or replaces the defective part. The owner pays labor and shipping.
Not coveredNormal wear such as bearings, crashes, misuse, improper assembly, and sports such as basketball, quad rugby and tennis
Age limitNo warranty on a wheel bought 4 or more years after it was made
This product cannot be returned
Wheels cannot be returned. Check the size, the hub and the spoke color on this page before you order. If they arrive damaged or defective, tell us within 48 hours of delivery and we will get them repaired or replaced at no cost to you.
If something goes wrong
Call us first at 1-855-HIELINE. We file the claim with Spinergy for you and get the covered part sorted out rather than handing you a phone number.
Is the price for one wheel or for a pair?
For a pair. One unit in the cart is two wheels.
What comes in the box?
Two wheels with their hubs and bearings. Handrims, tires, tubes and axles are not included.
What are rivnuts, and do I need them?
Rivnuts are threaded inserts set in the rim, and Spinergy uses them to bolt a handrim to a rim. Order the rim with rivnuts if you will fit handrims to these wheels.
Will a 507mm wheel fit my chair?
Spinergy describes 507mm as slightly larger than a 22" (501) wheel, and the tires made for it are wider and taller than a wheelchair tire. Check the room between your frame, your side guards and your wheel locks before you order.
Which tires fit?
Tires marked 507 on the sidewall. That is the size of youth mountain bike and BMX tires, and Spinergy names a mountain bike style tire or a large volume road tire for this wheel.
Which hub does it have?
Spinergy's SLX sport hub. It measures 2.3" from the outside of one bearing to the outside of the other and takes a 1/2" axle.
Which axle length do I need?
Axles are not included, and you can add a pair under "Add axles" on this page. The length depends on your chair. Spinergy's axle chart gives these lengths for the SLX, which has the same hub as this wheel. 4.25": Aria, Colours, GTM, Hands On Concepts, Ki Mobility, Kuschall, Melrose, Panthera, Reckless, TiLite, Vesco, P4X and the RGK Octane Sub 4 and Tiga. 4.50": Levo, Lifestand, Miki, Mogo, Motion Composites, Quickie and Roma. 4.75": Box, Brand New Wheelchair, Invacare, Top End and Lasher. 5.00": Kinesis. For the other RGK chairs the chart gives 4.75" or 5.12", so ask us before you order. Spinergy's price list has no 1/2" axle in 5.00", so that length is not offered on this page. A Ki chair with height adjustable armrests takes 0.25" more, except the Ethos, which takes 3.75". A Quickie more than 10 years old takes 0.25" less. If your chair is not on the chart, the length depends on two things: the length of the axle receiver in your camber tube, and the distance from the outside of one hub bearing to the outside of the other. Measure both and you have the axle length.
Spinergy shows this wheel with colored spokes. Can I order a color?
The dealer price list carries the SLX 507 with black spokes only, so black is what we list.
Why fiber spokes and not steel?
Spinergy rates its PBO fiber at three times the strength of steel and half the weight, and the fiber absorbs 25% more shock and vibration than a steel spoke.
What maintenance do the wheels need?
Keep them clean. Now and then take the wheels off the chair, pull the axle and wipe the bearings, the hub and the axle with a dry rag. The bearings are sealed and need no grease. Check that the spokes are tight, the rim is undamaged and the tires hold their pressure.
What is the warranty?
Spinergy warrants the wheels for 1 year from the date of purchase against defects in materials and workmanship, for the original owner. Keep your receipt. Bearing wear, crash damage and sports such as basketball, quad rugby and tennis are not covered.
Can I return them?
No. Wheels cannot be returned, so check the size, the hub and the spoke color before you order. If they arrive damaged or defective, tell us within 48 hours of delivery.
Is Hieline an authorized Spinergy dealer?
Yes. Hieline is a Spinergy dealer and orders these wheels directly from Spinergy, which makes them.
Build & Buy
Not includedHandrims, tires, tubes and axles.
Rim
Choose the rim with rivnuts if you will bolt handrims to these wheels. Rivnuts are threaded inserts set in the rim.
Hub
Add axles
Optional. The wheels ship without axles. Sold as a pair. The length depends on your chair: see "Which axle length do I need?" in the questions below.
